Product Details:
|
| Operating Temperature: | 0°C To 45°C | Ports: | 24 X 10/100/1000Base-T + 4 X 10 Gigabit SFP+ |
|---|---|---|---|
| Forwarding Performance: | 96 Mpps | Vlan Support: | 4096 |
| Dimensions: | 442 X 220 X 43.6 Mm | Switching Capacity: | 128 Gbps |
| Qos Support: | Yes | Stacking Capability: | Up To 9 Switches |
| Power Supply: | AC 110/220V | Model: | S5720-28X-PWR-LI-AC |
| Highlight: | 48 Port Gigabit Huawei Switch,4x 10G Uplinks Huawei Switch,SDN Support S5731-S48S4X |
||
High-Performance Huawei Switch : 48-Port Gigabit & 4x 10G Uplinks With SDN Support
The Huawei S5731-S48S4X is a next-generation enterprise-grade gigabit switch designed for high-speed connectivity, intelligent management, and scalable networking. Featuring 48x 1G Ethernet ports and 4x 10G SFP+ uplinks, it delivers high-density access and ultra-fast aggregation, making it ideal for medium to large businesses, campus networks, and data centers.
✔ High-Speed Connectivity – 48x Gigabit ports for high-density device access, plus 4x 10G uplinks for seamless backbone connectivity.
✔ SDN & Cloud-Ready – Supports OpenFlow, NETCONF/YANG, and Huawei CloudCampus, enabling automated network management and seamless integration with SDN architectures.
✔ Intelligent O&M – Huawei iPCA technology provides real-time network quality monitoring, reducing troubleshooting time by 50%.
✔ Enterprise Security – Advanced MACsec encryption, ACL, anti-ARP spoofing, and DHCP Snooping protect against cyber threats.
✔ Energy-Efficient Design – IEEE 802.3az (EEE) compliance reduces power consumption by up to 30%, lowering operational costs.
| Parameter | Specification |
|---|---|
| Ports | 48x 10/100/1000BASE-T, 4x 10G SFP+ |
| Switching Capacity | 336 Gbps |
| Forwarding Rate | 126 Mpps |
| Power Supply | AC (Dual PSU optional) |
| Security Features | MACsec, ACL, Port Security, IP Source Guard |
| Management | Web, CLI, SNMP, eSight, OpenFlow |
| Dimensions (WxDxH) | 442 x 420 x 44 mm |
Enterprise/Campus Networks – High-performance access and aggregation layer switching.
Data Center Edge – Reliable 10G uplinks for server connectivity.
SDN & Cloud Deployments – Programmable networking for agile IT environments.
The S5731-S48S4X combines speed, intelligence, and security in a single compact chassis. With SDN compatibility, AI-driven O&M, and energy-saving tech, it’s a future-proof investment for businesses upgrading their network infrastructure.
