Ruijie Switch RG-IS5200-8GT4XS 8-Port Gigabit + 4 SFP Web-Managed Secure Reliable L2 Switch

Large Image : Ruijie Switch RG-IS5200-8GT4XS 8-Port Gigabit + 4 SFP Web-Managed Secure Reliable L2 Switch

Product Details:

Brand Name:	Ruijie
Model Number:	RG-IS5200-8GT4XS

Contact Now

Ruijie Switch RG-IS5200-8GT4XS 8-Port Gigabit + 4 SFP Web-Managed Secure Reliable L2 Switch

Description

Model:	RG-S5750E	Operating Temperature:	0℃ To 45℃
Weight:	3.5kg	Port:	48*10/100/1000 Base-T Ports
Mac Address Table Size:	32K	Power Consumption:	Max. 50W
Poe Support:	IEEE 802.3af/at	Port Type:	RJ45
Dimensions:	440mm X 44mm X 220mm	Power Supply:	AC 100-240V, 50/60Hz
Forwarding Rate:	130.95Mpps	Vlan Support:	IEEE 802.1Q
Switching Capacity:	176Gbps	Poe Budget:	Max. 370W
Highlight:	Ruijie RG-IS5200-8GT4XS Switch , 8-Port Gigabit L2 Switch , Web-Managed L2 Switch

Ruijie Switch RG-IS5200-8GT4XS 8-Port Gigabit + 4 SFP Web-Managed Secure & Reliable L2 Switch

The Ruijie RG-IS5200-8GT4XS is a high-performance Layer 2 managed switch designed for small to medium-sized businesses, campuses, and surveillance networks. Featuring 8x Gigabit Ethernet ports and 4x SFP fiber slots (Combo ports), it delivers flexible connectivity for copper and fiber uplinks. With 56Gbps switching capacity and 41.7Mpps forwarding rate, it ensures smooth data transmission for bandwidth-intensive applications.

Key Features & Benefits

Smart Management: Easy Web GUI and CLI for configuration, plus optional cloud management (RG-SNC) for remote monitoring.
Enterprise Security: Port security, 802.1X authentication, ACLs, and anti-ARP spoofing protect against unauthorized access.
High Reliability: Supports STP/RSTP/MSTP and ERPS (<50ms failover) for uninterrupted network uptime.
Advanced QoS: Prioritizes VoIP, video, and critical traffic with 802.1p/DSCP and per-port bandwidth control.
Energy Efficient: Complies with IEEE 802.3az (EEE), reducing power consumption by up to 30%.

Technical Specifications

Model	RG-IS5200-8GT4XS
Ports	8x 10/100/1000Base-T, 4x 1000Base-X SFP (Combo)
Switching Capacity	56Gbps
Forwarding Rate	41.7Mpps
Management	Web, CLI, SNMP, RMON, Cloud (Optional)
Security	802.1X, Port Security, ACL, DHCP Snooping
Reliability	ERPS, STP/RSTP/MSTP, Dual Power (Optional)
QoS	802.1p, DSCP, 8 Priority Queues
Power Consumption	<15W (Typical)

Ideal Use Cases

Office Networks: Reliable connectivity for PCs, IP phones, and wireless APs.
IP Surveillance: Optimized for CCTV cameras with IGMP Snooping for multicast traffic.
Industrial Environments: Optional wide-temperature model (-40°C~75°C) available.
