Ruijie RG-S6520-64CQ Data Center Switch With 64x 100G Ports

Large Image : Ruijie RG-S6520-64CQ Data Center Switch With 64x 100G Ports

Product Details:

Brand Name:	Ruijie
Model Number:	RG-S6520-64CQ

Contact Now

Ruijie RG-S6520-64CQ Data Center Switch With 64x 100G Ports

Description

Product Type:	Switch	Power Consumption:	Max. 30W
Management Interface:	Web, CLI, SNMP	Forwarding Rate:	Up To 71.4 Mpps
Product Series:	Ruijie Switch	Qos Support:	Yes
Vlan Support:	Yes	Switching Capacity:	Up To 128 Gbps
Number Of Ports:	24/48	Port Speed:	10/100/1000 Mbps
Port Type:	Ethernet	Model:	Ruijie Switch
Highlight:	64x 100G Ports Data Center Switch , RG-S6520-64CQ Data Center Switch

High-Density 100G Ports & RDMA Support - Data Center Ruijie Switch RG-S6520-64CQ

Product Attributes

Attribute	Value
Product Type	Switch
Power Consumption	Max. 30W
Management Interface	Web, CLI, SNMP
Forwarding Rate	Up to 71.4 Mpps
Product Series	Ruijie Switch
Qos Support	Yes
Vlan Support	Yes
Switching Capacity	Up to 128 Gbps
Number Of Ports	24/48
Port Speed	10/100/1000 Mbps
Port Type	Ethernet
Model	Ruijie Switch

Product Description

The Ruijie RG-S6520-64CQ is a high-performance data center switch designed for modern cloud, AI, and storage networks. Featuring 64x 100G QSFP28 ports, this switch delivers ultra-low latency, scalable bandwidth, and advanced virtualization for demanding workloads.

Key Features & Benefits

High-Density 100G Connectivity: 64x 100G ports (configurable as 40G/25G via breakout cables) enable flexible deployment in spine-leaf architectures.
RDMA over Converged Ethernet (RoCEv2): Optimizes AI/GPU and storage traffic with lossless low-latency forwarding, improving efficiency for NVMe-oF and distributed computing.
Data Center Virtualization: Supports VXLAN/EVPN for seamless multi-tenant isolation and hybrid cloud integration.
Carrier-Grade Reliability: Dual hot-swappable power supplies, MLAG (Multi-Chassis LAG), and sub-second failover ensure 99.999% uptime.
Telemetry & Automation: Real-time monitoring via INT (In-band Network Telemetry) and compatibility with SONiC/ONIE for SDN/NFV deployments.

Technical Specifications

Category	Details
Ports	64x 100G QSFP28 (1/40/100G capable)
Switching Capacity	Up to 12.8 Tbps
Forwarding Rate	Up to 9,520 Mpps
Latency	<1μs (cut-through mode)
Redundancy	Dual power supplies, N+1 fan modules
Protocols	BGP/OSPF/VXLAN/EVPN/RoCEv2/DCQCN
Management	SeerEngine SDN, CLI, SNMP, NETCONF

Why Choose the Ruijie RG-S6520-64CQ?

Ideal for hyperscale data centers, AI training clusters, and distributed storage, the RG-S6520-64CQ combines high-density 100G ports, RDMA acceleration, and open networking support. Its modular design and energy-efficient cooling (typical power consumption: <800W) reduce TCO while meeting Tier-3+ infrastructure demands.
