Ruijie Switch RG-S6510-32CQ 32-Port 100G 40G Data Center Switch

Large Image : Ruijie Switch RG-S6510-32CQ 32-Port 100G 40G Data Center Switch

Product Details:

Brand Name:	Ruijie
Model Number:	RG-S6510-32CQ

Contact Now

Ruijie Switch RG-S6510-32CQ 32-Port 100G 40G Data Center Switch

Description

Power Consumption:	Max. 40W	Vlan Support:	Yes
Model:	Ruijie Switch	Product Family:	Ruijie Switch
Number Of Ports:	24/48	Management Interface:	Web/SNMP/CLI
Port Speed:	10/100/1000 Mbps	Poe Budget:	370W
Port Type:	Ethernet	Product Type:	Switch
Stacking Capability:	Yes	Poe Support:	Yes
Highlight:	32 Port 100G Data Center Switch , Ruijie Switch , 40G Data Center Switch

Ruijie Switch RG-S6510-32CQ 32-Port 100G/40G High Performance & Data Center Ready

Product Overview

The Ruijie RG-S6510-32CQ is a high-performance data center and core-layer switch designed for ultra-high-speed networking. Featuring 32 flexible QSFP28 ports (supporting 100G or 40G), it delivers 12.8Tbps switching capacity and 5.952Bpps forwarding rate, making it ideal for cloud computing, AI workloads, and large-scale enterprise networks.

Key Features & Benefits

High-Density 100G/40G Ports - Each QSFP28 port can be split into 4x25G or 4x10G, enabling flexible deployment in evolving networks.
Data Center Optimized - Supports VXLAN, EVPN, and Cut-Through forwarding for low-latency, scalable SDN environments.
Carrier-Grade Reliability - Dual hot-swappable power supplies (1+1 redundancy) and IRF2 virtualization for seamless failover.
Intelligent Management - Telemetry, sFlow/netFlow, and RIIL network management for real-time monitoring and troubleshooting.
Energy Efficient - 80Plus Platinum PSUs and dynamic fan control reduce power consumption.

Technical Specifications

Parameter	Specification
Ports	32 x QSFP28 (100G/40G, split to 25G/10G)
Switching Capacity	12.8Tbps
Forwarding Rate	5.952Bpps
Latency	<1μs (Cut-Through mode)
Redundancy	Dual power, N+1 fan
Virtualization	IRF2 (up to 4 devices)
Protocols	VXLAN, EVPN, BGP, OSPF, MLAG
Management	CLI, Web, SNMP, RIIL, Telemetry
Power Efficiency	80Plus Platinum, <300W typical

Product Attributes

Attribute	Value
Power Consumption	Max. 40W
Vlan Support	Yes
Model	Ruijie Switch
Product Family	Ruijie Switch
Number Of Ports	24/48
Management Interface	Web/SNMP/CLI
Port Speed	10/100/1000 Mbps
Poe Budget	370W
Port Type	Ethernet
Product Type	Switch
Stacking Capability	Yes
Poe Support	Yes

Ideal Use Cases

Cloud & Hyperscale Data Centers - High-bandwidth spine-leaf architectures.
Enterprise Core Networks - Future-proof backbone for campuses and large offices.
HPC & AI Clusters - Low-latency, lossless networking for GPU workloads.

With its scalable 100G/40G architecture, advanced automation, and carrier-class reliability, the Ruijie RG-S6510-32CQ is a top-tier choice for next-gen networks.
