Ruijie Dual-Band Wireless AP 1.567Gbps MU-MIMO Enterprise WiFi

Large Image : Ruijie Dual-Band Wireless AP 1.567Gbps MU-MIMO Enterprise WiFi

Product Details:

Brand Name:	Ruijie
Model Number:	RG-AP180-L-A(V3)

Contact Now

Ruijie Dual-Band Wireless AP 1.567Gbps MU-MIMO Enterprise WiFi

Description

Number Of Antennas:	2	Dimensions:	180mm X 180mm X 40mm
Security Features:	WPA/WPA2, MAC Address Filtering, VLAN	Frequency Band:	2.4GHz/5GHz
Ethernet Ports:	1	Maximum Data Transfer Rate:	1200Mbps
Weight:	0.5kg	Power Over Ethernet (Poe):	Yes
Management Interface:	Web-based, CLI	Wireless Standard:	802.11ac
Operating Temperature:	0°C To 40°C	Power Supply:	DC 12V/1A
Highlight:	Ruijie dual-band wireless AP , enterprise WiFi MU-MIMO AP , 1.567Gbps wireless access point

High-Speed 1.567Gbps WiFi & MU-MIMO Enterprise-Grade Ruijie Wireless AP

Product Overview

The Ruijie RG-AP180-L-A(V3) is a high-performance dual-band wireless access point (AP) designed for enterprise-grade WiFi networks, delivering 1.567Gbps total throughput (300Mbps on 2.4GHz + 1.267Gbps on 5GHz) with 802.11ac Wave 2 technology. Featuring MU-MIMO (Multi-User MIMO), it ensures smooth connectivity for high-density environments like offices, schools, and retail spaces.

Key Features & Benefits

Blazing-Fast WiFi - Combines 2.4GHz & 5GHz bands for optimized speed and reduced interference
MU-MIMO Technology - Supports multiple devices simultaneously, improving efficiency in crowded networks
Enterprise Security - WPA3 encryption and VLAN support for secure, segmented network access
Easy Deployment & Management - PoE (802.3af) powered, cloud-manageable via Ruijie Cloud (RCC), and compatible with WS controllers
Smart RF Optimization - Auto channel selection & power adjustment for stable, interference-free performance

Technical Specifications

Category	Specifications
WiFi Standards	IEEE 802.11a/b/g/n/ac Wave 2
Max Speed	1.567Gbps (2.4GHz: 300Mbps + 5GHz: 1.267Gbps)
Antennas	Internal high-gain omni-directional
MIMO Support	2x2 MU-MIMO
Security	WPA3, WPA2, 802.1X, VLAN, MAC filtering
Management	Ruijie Cloud (RCC), WS Controllers, Standalone Fat AP mode
Power Supply	802.3af PoE or 12V DC adapter
Operating Temp.	0°C to 40°C (32°F to 104°F)
Mounting	Wall/Ceiling

Product Attributes

Attribute	Value
Number Of Antennas	2
Dimensions	180mm x 180mm x 40mm
Security Features	WPA/WPA2, MAC address filtering, VLAN
Frequency Band	2.4GHz/5GHz
Ethernet Ports	1
Maximum Data Transfer Rate	1200Mbps
Weight	0.5kg
Power Over Ethernet (PoE)	Yes
Management Interface	Web-based, CLI
Wireless Standard	802.11ac
Operating Temperature	0°C to 40°C
Power Supply	DC 12V/1A

Ideal Use Cases

Business Offices - Reliable WiFi for video calls & cloud apps

Education - Supports 30+ concurrent users in classrooms

Retail & Hospitality - Stable guest WiFi with captive portal

Upgrade your wireless network with the Ruijie RG-AP180-L-A(V3) - a powerful, secure, and scalable WiFi solution for enterprises!
